Intrinsically Safe Thermal Imaging Camera DORLAND - for Industry - Dorland
Company Advantages
· Dorland intrinsically safe thermal imaging camera is designed as per the consumers' needs and high-quality standards.
· Its quality can be guaranteed through fully mature quality test.
· It is recognized by the majority of users in different occasions.
Product parameters
| Brand | DORLAND |
| Model Name | EX Ti50F |
| Form Factor | Temperature measuring thermal imager |
| Explosion proof level | Ex ib IIC T4 Gb/Ex ib IIIC T130℃ Db |
| Protection level | IP54 |
| Certificate No. | SYEx24.0286X |
| Resolving power | 120*90 |
| Field of view angle | 50°*37°/0.5m |
| Like element size | 17μm |
| Range | -20 ℃ to 150 ℃/0 ℃ to 550 ℃ |
| Thermal sensitivity | ＜ 0.05 ℃ @+30 ℃/50mk |
| Visible light pixels | 2 million pixels |
| Display screen | 3.5 "640 * 480 pixels, touch screen |
| Image display mode | Infrared image, visible light image, picture in picture function, AUF automatic fusion |
| Palette | Iron Red, Rainbow, Grey White, White Grey, Blue Red, Hot Cold, Feather Red, Brown |
| Image frame rate | 50 Hz |
| Focusing method | No focusing |
| Storage | Built in 4GB |
| USB connection | USB type C, can connect to a computer |
| Battery | 2180mAh, 3.85VDC rechargeable lithium battery, available for 4 hours |
| Size | 80*52*18mm |
| Weight | 130g |
Download instructions
Download product information
product display
Company Features
· Beijing Dorland System Control Technology Co., Ltd. is a globally competitive firm focusing on producing intrinsically safe thermal imaging camera.
· The Dorland must adhere to the road of developing technological innovation. With the development of society, the technical strength of Dorland continues to increase. From technicians to production equipment, Dorland has a complete set of production processes.
· From the close relationships with our clients, we gain an even better level of understanding about our their needs to develop more precise analyses to ensure we deliver the best possible service. Get price!
Product Details
With a focus on quality, Dorland pays great attention to the details of intrinsically safe thermal imaging camera.
Product Comparison
Dorland's technical level is higher than its peers. Compared with peer products, the intrinsically safe thermal imaging camera produced by us has the following highlights.
